GouMax Type II dual-channel Laser Scan Analyzer (LSA-220DC) product is a multi-function power meter module. It is called "Laser Scan Analyzer" because LSA-220DC module is usually used in various applications to measure powers in conjunction with laser scanning.sweeping. It consists of high-speed power meters used to measure powers with synchronized high-speed laser sweeping. Like LSA-220A, LSA-220DC can provide wavelength reference. Like LSA-220B, LSA-220DC provide two test channels. Specifically, LSA-220DC module can provide the following functions:

• It can be simply used as two-channel power meters to measure static laser output powers
• Built-in wavelength reference
• It measures powers of high-speed sweeping laser
• It measures wavelength of sweeping laser and provides wavelength reference
• It provides power reference for relative power measurements

Figure 1: Dual-Channel LSA-220DC Module

• High-speed scan 1×2 or 2x2 test channels (Two channels)
• Real-time power reference
• 70 dB dynamic range detection
• Capacity increase by adding more LSA-220B modules in paralell
• Can use interlnal PD or external PD



• Passive fiber-optic component characterization
• Optical parameter measurement
• Production line automation
• Optical filter inspection



Full-band LSA-220DC modules support wavelength range from 1250 nm to 1650 nm. R50 model is used for both DWDM and CWDM applications. R200 model is suitable for CWDM measurements.

For details, please request specifications from GouMax Sales.
